Eaton SP4-LOC-SB Local Operator Console, Surface Mount, Red

Description

TheSP4 –LOC Remote Microphone and Local Operator Console is designed to be used with the Facility Communications System using the SafePath4 SP40/2 and the SP40S panels.

It contains the SafePath4 SPRM Remote Microphone Module and eight black Push On /Push Off buttons which provide a contact closure to activate the SP40/2 or the SP40S digital messages in the Push On position.

Main Features

• All message Wiring is pre-wired to a terminal block
• Built-in SPRM requires 24V DC, supplied by the SP40S
• All output circuitry is Power Limited
• Internal terminal block accepts up to 16 AWG wiring for filed wiring
• SPRM Input current: Standby: 26mA Alarm: 38mA
• SP4 LOC is available in flush and surface models
• Backbox for both models are identical with knockout mounting holes in the sides and back
• Can be mounted up to 2,000 feet away from the SP40/2 or SP40S
• Remote microphone usage disengages background music and general paging

NOTE: Product currently out of stock which will delay delivery by 2 to 3 weeks
